RSK-n- eupex SERIES A type FLEXIBLE COUPLINGS overload-holding simple construction

RSK-n- eupex pin couplings connect machines.They compensate for shaft misalignment,generating only low restorative forces.The torque is conducted through elastomer flexibles so the coupling has typically flexible rubber properties.

RSK-n- eupex couplings are overload-holding. By contrast,the RSK-n- eupex DS series is designed so that overload or advanced wear causes irreparable damage to the elasto-mer flexibles. The metal parts of RSK-n- eupex couplings can then rotate freely against one another without contact.

Benefit

RSK-n- eupex couplings are designed on the modular principle and have a very simple construction. RSK-n- eupex types are made up of sub assemblies to suit requirements. The couplings are assembled by simply fitting the coupling halves together. Wear is restricted to the elastomer flexibles, which must be replaced at the end of their service life.

Application

Depending on type, the elastomer flexibles can be changed without moving the coupled machines.The coupling parts are readily available from stock and are mostly finish-machined, i.e. with finished bore, keyway setscrew and balancing.

RSK-n- eupex pin couplings connect machines.They compensate for shaft misalignment,generating only low restorative forces.The torque is conducted through elastomer flexibles so the coupling has typically flexible rubber properties.

RSK-n- eupex couplings are overload-holding. By contrast,the RSK-n- eupex DS series is designed so that overload or advanced wear causes irreparable damage to the elasto-mer flexibles. The metal parts of RSK-n- eupex couplings can then rotate freely against one another without contact.

Benefit

RSK-n- eupex couplings are designed on the modular principle and have a very simple construction. RSK-n- eupex types are made up of sub assemblies to suit requirements. The couplings are assembled by simply fitting the coupling halves together. Wear is restricted to the elastomer flexibles, which must be replaced at the end of their service life.

Application

Depending on type, the elastomer flexibles can be changed without moving the coupled machines.The coupling parts are readily available from stock and are mostly finish-machined, i.e. with finished bore, keyway setscrew and balancing.
