RSK-TBT 8 ZT High torsional stiffness diaphragm coupling for testing bench

Contact Us
  • Specification
  • Describe
Specification

Model: RSK-TBT8  8102F  8102 8132 8178 8210 8252
Rated Torque  TKN N.m  190 300 1100 3500 5800 10000
Peak Torque  TKS N.m  285 450 1650 5250 8700 14250
Outer Diameter  mm  102 102 132 178 210 252
Hole Diameter mm  25-45H6  25-45H6  45-70H6  50-85H6  60-100H6  70-120H6
Maximum Speed Nmax min−1  18000 18000 15000 12000 10000 8000
  Axial Offset   △Ka mm  1.1 0.8 1.1 1.2 1.4 1.6
Radial Offset   Sleeve 1  △Kr mm  0.3 0.2 0.25 0.25 0.35 0.4
Sleeve 2  △Krh mm  1 0.7 1 1.25 1.35 1.7
Angular Offset      °  1 0.7 0.6 0.5 0.5 0.5
Angle Spring Stiffness    Nm/rad  229 285 1850 6980 11250 18580
Diaphragm Set Thickness  mm  7.1 4.6 6.8 11.2 12 14

Note: For speeds over 5000rpm, the offset should be controlled to a maximum of 30%.
